Bolt high-speed cinebot
Ultra highspeed moves
Bolt has the ability to get up to speed instantly - moving from standstill to highspeed motion, and back again, in only a fraction of a second. The robotic arm allows the camera to literally follow falling objects and capture images that would be impossible to record using any other method.
Precision and repeatability
Bolt is the perfect rig to use in combination with a Phantom camera. The ultra-fast repeatable moves open new possibilities in creating slow-motion shots. Any move can be accurately repeated at any speed. Even time-lapse shots can be achieved with Bolt movement!
Synchronises with other rigs
Bolt interfaces to any external triggers, model-movers, turntables and other rigs for perfect timing - every take! This is essential when shooting complex special effects shots that require reliable repeatability!
Specifications
-
Max camera height from ground 3.5 m
-
Lowest camera position 0 m
-
Max reach from rotate center 2 m
-
Track length 9 m
-
Track max speed 4 m/s
-
Max camera payload 20 kg
-
Max 360 degree circle diameter 80 cm
-
Max 180 degree arc diameter 3 m
-
Time lapse / stop frame possibility Yes
-
Compatible cameras Phantom Flex (any model), Arri Alexa Mini, Red cameras and more
-
Lens motors 2 x focus and zoom
-
Dimensions transport - Bolt base width 1.2 m x length 1.4 m x height 1.5 m
-
Dimensions transport - Bolt track width 80 cm x length 3 m x height 1 m
-
Weight Bolt base 600 kg
-
Power connection 3x 400 V, 32 A
Rental kit includes
- Bolt robotic arm with 3x3 m track
- Control computer system
- 2 x lens motors with remote control unit
- Operator HD SDI monitor
- Camera plate for Phantom - Alexa Mini - Red
- Transport not included
